Light Sensor BS300
BS300
BS300 is an automatic photocell switch for lamps. It detects the ambient light level and controls the light. The light will turn on when the ambient light level is lower than the user-selected LUX value and turn off when the ambient light level is higher than the LUX value.
BS300 has two working modes. In dusk to dawn mode, the light stays on all night and turns off in the daytime. You can also set a timer from 1 to 9 hours to let the light only stay on for a certain time at night.
Not what you’re looking for? View our portfolio:
Consult an Expert
BS300 Light Sensor Switch
BS300 is an automatic photocell switch for lamps. It detects the ambient light level and controls the light. The light will turn on when the ambient light level is lower than the user-selected LUX value and turn off when the ambient light level is higher than the LUX value.
BS300 has two working modes. In dusk to dawn mode, the light stays on all night and turns off in the daytime. You can also set a timer from 1 to 9 hours to let the light only stay on for a certain time at night.
Features, Benefits, Specs
Features & Benefits
- LUX: Turn to the MOON position anticlockwise – the photocell will only work in the dark(less than 3LUX). Slowly turning to the SUN position clockwise will set the LUX value from dusk(3LUX) to dawn(200LUX).
- Dusk to Dawn: The light stays off in the daytime and keeps on the entire night
- TIMER: Users can select a timer range from 1 to 9 hours. When the light turns on, it will stay on for that certain amount of time and then turns off automatically.
Specifications
- Features
-
Power source
220V – 240V/AC
Power Frequency
50Hz
Rated Current
6A
Ambient Light
<3-200LUX(adjustable)
TIMER setting range
1 ~ 9 hours adjustable, or Dusk to Dawn
Working Temperature
-20~+40℃
Working Humidity
<93%RH
