Occupancy / Vacancy / Manual Motion Sensor Switch, Neutral Required, UK
$16.00
RZ023-10A motion sensor switch, 100~265V, 10A. Direct replacement for British standard wall switch. Neutral wire required. Advanced PIR motion sensor for accurate motion detection. Occupancy/Vacancy mode with Rayzeek’s exclusive manual ON/OFF mode.
Rayzeek’s manual ON/OFF mode allows users to keep the load always ON/OFF, just like a regular wall switch. By simply pressing a button on the panel, you can change from Occpuacny/Vacancy mode to manual mode and vice versa without losing any settings. This feature allows users to have permanent manual control of the load and override the motion detecting mode when in need.
This motion sensor light switch also allows users to temporarily turn ON/OFF the light without exiting the current detecting mode and allows 6 levels of time delay adjustment from 15 s to 30 mins and 3 levels of light sensor adjustment from OFF, 15 lux to 35 lux. RZ023-10A provides maximum flexibility and is competent for every home&commercial use case.
- Sensor Modes: Occupancy, Vacancy and Manual modes.
- Sensors: PIR motion sensor. Light sensor(photocell).
- Features: Adjustable time delay and light sensor.
- Wiring: Hot, live, neutral wire.
- Use Cases: Living rooms, bathrooms, offices. Anywhere a regular single pole light switch is used due to the ON/OFF mode.
Product highlights
- Manual mode allows the switch to work exactly like a light switch
- 100~265V line voltage, 10A current rating
- Neutral Required. British standard.
- Occupancy, vacancy, manual override 3-in-1
Not what you're looking for? View our portfolio:
Consult an Expert
Motion Sensor Light Switch
It’s never too late to experience convenient, energy-saving, and hands-free motion-activated lighting. Easily save up to 60% of energy and reduce your electricity bills with a simple upgrade to motion sensor light switches.
The versatile RZ023 motion sensor switch is applicable for every residential and commercial application with occupancy, vacancy, and ON/OFF modes integrated for max compatibility, flexibility, and ease of use.
10 Minute Quick Installation
The RZ023-10A series is designed for the UK markets for single-pole applications. The 100V-265V voltage range works well in homes and offices and the 10A current rating is capable of high load commercial grade applications.
RZ023-10A is a 3-wire switch and requires a neutral wire to work.
Exclusive ON/OFF Mode
One significant drawback after upgrading to motion-activated light switches is that you partially lose the ability to manually control your lights. It’s not possible to keep the lights ON like you’re used to with the good old wall switch.
The Best Of Both Worlds?
Rayzeek introduces the exclusive ON/OFF mode, allowing users to permanently keep the load ON or OFF the same as a standard light switch. It’s so convenient that users can seamlessly switch between detection mode and manual mode with only one tap.
Say goodbye to all these real-life headaches.
Pets Activate the Light at Night
Dogs and cats are active at night and might frequently trigger your motion light to turn on. That’s their nature. While most motion sensor switches do not have pet-immune features, false positives at night can be a real headache.
Select vacancy or OFF mode, especially in laundry rooms or the kitchen where your pets usually play around.
Take a Relaxing Long Bath
On average, people spend at least 8 minutes in the shower. When taking a relaxing bath at night, the light might unexpectedly turn off if the sensor can’t detect your presence in the bathing area. It can be an unpleasant experience that spoils the mood
Enter ON mode to keep the light always ON during the shower. Enjoy your hot and relaxing bath for as long as your like.
Lighting in Your Kids’ Bedroom
A vacancy sensor switch is used in bedrooms to reduce the electricity waste from the lighting left on by forgetful kids. Occupancy sensors aren’t suitable because they might activate the light at night, waking up kids, but it’s still handier in the daytime.
Now you can use occupancy sensor mode in your kid’s bedroom for the whole day. When it’s bedtime, touch the OFF button to keep the light off for the whole night.
Light False on in Empty Spaces
A fixed heat source(HVAC or hot wind) or even mirror reflection may send false positive IR signals that keep the light on when the space is unoccupied. Most of the time, it’s impossible to relocate the sensor’s position or the heat source as they’re fixed.
When the PIR sensor constantly detects signals and is falsely triggered, select OFF Mode to bypass motion detection
False off With People in the Room
Lights might falsely turn off if the sensor fails to detect the presence of people, e.g., the room is large, has obstacles blocking the IR signal, or fine motion activities such as reading or typing. It’s frustrating to repeatedly re-activate lights by moving your body.
When we need to permanently keep the light ON, enter ON mode by tapping the small button and exit without losing previous settings.
Features, Benefits, Specs
The ultimate energy-saving & lighting automation solution – switch from Auto ON/Auto OFF, Manal ON/Auto OFF, and Manal ON/Manual OFF operating mode for your multi-purpose rooms.
Features & Benefits
- Occupancy, Vacancy, Manual ON/OFF mode 3 in 1
- Exclusive ON/OFF mode allows the sensor switch to work the same as a standard light switch
- Time delay options: 15s, 1 min, 3 mins, 5 mins, 15 mins, 30 mins
- Enable ambient light sensor to keep lights off when there is ample natural light
- Low and high sensitivity adjustable
- Adjust settings by tapping buttons without removing the switch plate
- Magnetic latching relay provides better performance
- Made of fire-resistant materials for your safety
- RoHS, CE, FCC certified
- Features
Sensor Mode
Vacancy mode, Occupancy mode, Manual ON/OFF mode
Time-Delay
15 s, 1 min(default), 3 mins, 5 mins, 15 mins, 30 mins
Light Sensor
Off, 15 Lux, 25 Lux (default), 35 Lux
Sensor Sensitivity
Low Sensitivity, High Sensitivity
- Working Conditions
Power Source
100 VAC ~ 265 VAC
Power Frequency
50 / 60Hz
Installation Height
1.2 m ~ 1.6 m
Working Humidity
< 93%RH
Working Temperature
-20 ~ +40℃
- Detection Capability
Detection Distance
7 m ~ 10 m (<27℃)
Detection Range
< 150°
Detection Speed
0.6 ~ 1.5m/s
- Bulb Compatibility
Fluorescent / Ballast / LED
1000 W / 220 VAC
Incandescent / Halogen
2200 W / 220 VAC
The Ideal Repalcement
The Rayzeek RZ023 motion sensor switch is ideal for replacing wall switches in the UK area and countries utilizing the British standard 86 type square wall switch boxes. The 100V- 265V wide voltage range makes RZ023 applicable to all regions using 220V to 240V AC voltages.
RZ023-10A
- 10A Load: Ideal for high load applications, i,e, controlling multiple lights or HVAC
- 3-Wire Wiring: Hot Wire, Load Wire, Neutral Wire
UK Standard Switch
RZ023 motion sensor switch is designed for the UK market and fits in the standard 86 type pattress boxes. Also suitable for countries using British standard back boxes:
- United Arab Emirates
- United Kingdom
- Hong Kong
- Ireland Israel
- Malaysia
- Portugal
- Saudi Arabia
- Singapore
- Turkey
Versatile Applications
Rayzeek RZ023 motion sensor switch is the ultimate solution for automating your home lighting. It can act as an occupancy sensor, vacancy sensor, or a standard light switch to suit the diverse needs of every space. Simply upgrade all your light switches with RZ023 without a second thought because you can always change it to a manual ON/OFF switch when needed.
Bathroom
Occupancy sensor with light sensor enabled is the ideal mode for bathroom usage, especially when you need to use it at night. Manual ON mode can be suitable for long showers.
Garage
Walk in and out of your home garage without the need to reach the light switch with an occupancy sensor switch. Enable daylight sensing to save more energy in the daytime.
Laundry Room
Enjoy the automatic lighting turned on and off for you when arm-full with piles of laundry to wash or clean clothes to take away.
Kitchen
Place an occupancy sensor switch at the entrance and enjoy the automatic lighting while you’re busy cooking and preparing food for your family.
Hallway
Occupancy/vacancy sensor switches can reduce the hours of lighting used by approximately 53% on dark hallways in your basement.
Breakroom
Occupancy sensors can reduce energy waste by 39% and increase energy-saving up to 17% with a 20-minute time delay for breakrooms.
Private Office
Rayzeek motion sensor switches provide max flexibility for office use cases. Occurpnay, vacancy or manual mode, your office, your call.
Conference Room
Vacancy switch with manual override feature is perfect for conference rooms where it’s not frequently used and requires manual turn on and off for presentations.
Videos
RZ023 User Guide
RZ023 Programming Guide
RZ023 (Neutral Required) – Installation Video
Fire Resistance Testing – RZ023
Load Testing
